DigiSilo Radar Sensor
The Beiselen Service GmbH DigiSilo is a compact distance measurement device and presence detector that consists of low power, high precision, pulsed short-range radar sensor and can measure in a distance range from 50 cm to 7 meters. DigiSilo is made for silo monitoring with different mediums like grain, feedstock, flour, or liquids.
About this device
The Beiselen Service GmbH DigiSilo is a compact distance measurement device and presence detector that consists of low power, high precision, pulsed short-range radar sensor and can measure in a distance range from 50 cm to 7 meters. DigiSilo is made for silo monitoring with different mediums like grain, feedstock, flour, or liquids.
The DigiSilo Radar Sensor supports 1 regional frequency plan and operates as a Class A LoRaWAN device.
Key features
- Sensors: distance, motion.
- 1 frequency plan supported: EU863-870.
- Battery powered (lithium-ion), user replaceable.
Vendor
Hardware specifications
| Model ID | radar |
| Dimensions | 280 × 125 × 60 mm |
| Weight | 725 g |
| IP rating | IP67 |
| Operating temperature | -30 °C to 60 °C |
| Power | Battery — lithium-ion, replaceable |
Certifications & compliance
Standards
Network profiles
Capabilities are defined per firmware version and frequency plan, exactly as published in the repository.
Firmware 1.0
| Frequency plan | MAC | Reg. params | Class | Join | Max EIRP | Certified |
| EU863-870 | 1.0.2 | RP001-1.0.2-RevB | A | OTAA | 16 dBm | — |
Frequency plan coverage
Add to The Things Stack
Manual setup
Create an application
In The Things Stack console, go to Applications → Create application and pick a unique application ID.
Register an end device
Choose From the LoRaWAN Device Repository and search for “DigiSilo Radar Sensor”. Select your firmware version and frequency plan.
Enter device credentials
Provide the DevEUI, JoinEUI and AppKey printed on the device label or QR code.
Power on & verify uplinks
Within a few minutes you'll see the join request and uplinks in the Live data tab.
