ACCELEROMETER

Accelerometer Sensor

Made by
Move Solutions is a certified partner.
Contact this partner →

Description

The Move accelerometer can measure the acceleration of the point where it is installed, on the three axes, with high resolution. Like other devices, it is fully wireless, and the battery lasts for years, in relation to the transmission frequency (timed and/or by threshold exceeding). It is great for dynamic monitoring and modal study of large structures, the move accelerometer also integrates a temperature sensor inside.

# End Device
# EU 863-870
# Industrial IoT
# Logistics
# Outdoor
# Smart Building

Specifications

  • Acquisition of Acceleration and Temperature
  • High Accurarcy
  • Fit to industrial environment (IP67 Protection)
  • Long-range capacity due to the external antenna
  • Battery powered device with long battery life
  • LoRa® Communication Technology
  • Smart installation with wall, floor or ceiling

Technical details

  • Solution for monitoring of Buildings, Bridges and Overpass, Dams, Smart Industries, Underground works, and Smart Operations
  • LoRa Class A - Class B, Adaptive Data Rates (ADR), Spreading Factors, Channel Diversity, compatible with LoRaWAN Gateway
  • Resolution 14 bit (250 μg, 500 μg, 1mg)
  • Temperature resolution 0,125°C
  • 2 years of battery life
  • Radio Channel Frequency ISM 868 MHz
  • Waterproof rating IP67
  • 1 lithium battery type “D” 19Ah 3.6V
  • -40°C / +85°C operating temperature
  • Dimension of case 75x80x57mm
