AM094

High-performance LoRaWAN modem

Made by
WYLD Networks is a certified partner.
Contact this partner →

Description

The Wyld Networks AM094 wireless modem is a high-performance modem at 868 and 915 MHz which includes the TRIoT® stack: Wireless M-Bus, LoRa® and LoRaWAN®. Ideal for Smart Metering, Building Automation, Smart City and other IoT applications using networks that implement these protocols.

The AM094-LW radio module provides a highly integrated long range solution for 868 and 915 MHz applications embedded modem. It is also suitable for other 868 MHz ISM-band communications standards. The Wyld Networks AM094 wireless modem supports very low current standby for battery powered applications. Wyld Networks also provides full integration support of our technology including customisation of hardware, software and product development.

# End Device
# EU 863-870
# Modules
# Smart Building
# Smart City
# Smart Metering
# US 902-928

Specifications

  • TRIoT® stack included
  • Unique bridging function between protocols
  • Long range bidirectional modem
  • LoRaWAN® 1.0.3 compliant firmware included
  • Full access to MCU – run your own code
  • Link budget 151 dB
  • AES128 encryption/decryption
  • Low power – 2.2 μA in sleep mode
  • Firmware updates by bootloader
  • Evaluation kit AE094 available

Technical details

  • Wyld Networks AM094 Wireless Modem
  • Use in stand-alone modem mode, or embed user application on-board
  • Link RF Performance
  • Receive sensitivity to -119dBm in FSK mode
  • Receive sensitivity to -137dBm in Spread Spectrum mode
  • AT command set Interface
  • Software
  • LoRaWAN®1.0.3 Class A
  • LoRaWAN® Class B and C supported
  • The TRIoT stack
  • Transmit RF Performance
  • +14dBm at 3.3V
  • Long-Range Operation
  • Spread spectrum operating mode using LoRa®
  • Increases link budget by up to 25dB
  • Exceptional transmission range (up to 15km)
  • For use in radio-poor environments
  • Hardware
  • NXP Kinetis family ARM® 32-bit Cortex
  • M0+ MCU
  • Semtech SX1272 transceiver
