ATEX PULSE SENSOR
ATEX PULSE SENSOR (ComBox.L 01) can be used with any meter with a pulse signal output (such as electricity, gas, water, heat). It provides comprehensive data to meet the needs of meter management and consumption monitoring. Pulses can be aggregated from 1 minute intervals. It can connect up to 2 meters, both connections have tampering detection. ComBox.L range is LoRaWAN and ThingPark approved, due to their external antenna and their industrial design they have high sensitivity of connectivity and allows installation in any harsh environment. The Atex certification allows the usage in hazardous zone 1 and 2.
Key features highlights:
ComBox.L O1-Atex Pulse
Connect two input for one pulse meters and one tempering
Battery powered device with long autonomy
Collect data from different meters such as Electricity or Gas or Water equipped with a pulse output
Fit to industrial environment IP 67 protection
Data accuracy for smart metering and energy management
Long range capacity due to external antenna
Atex certified Zone 1 & 2 (II 2G Ex ib [ib] IIB T4 Gb)
Tampering detection in case of cable disruption
Data logging, time synchronization, remote configuration
Certified LoRaWAN® 1.0.1
Seller SKU ComBox.L 01-B Atex pulse sensor (868Mhz)
LoRa Class Class B
Solution Represented Smart Cities, Smart Industries, Other
Battery specification (Wh) 2x2600mAh AA
RF power (dBm) 14 dBm
Antenna External on connector
RF transceiver SX1276
Interfaces Analog
Depth (cm) 9
Width (cm) 4,3
Height (cm) 20
Technical docs
Product Datasheet
Installation Guide
Certification LoRa® Alliance, CE
*Is available for sale Yes
Lead-time if in Stock (in working days) 45
RADIO
• Frequency: 868 MHz
• Modulation: LoRa
• Max. wireless power:14 dBm
2. INPUT
• No. of digital inputs: 1 (potential free contact)
• No. of analog inputs: 1 (Hall Effect Sensor)
•
3. POWER
• Battery: 2x lithium-thionyl chloride (Li-SOCl2)
• Battery Voltage: 3,6 V (nominal)
• Battery Capacity: 2600 mAh per battery
• Battery manufacturer: SAFT (LS14500Ex)
4. TEMPERATURE
• Max amb. temperature: from -20 °C to +60 °C
5. HOUSING
• Dimensions: 200 x 90 x 43 mm
• Weight: 280 g
• IP Protection: IP67 (IEC 60529)
