COMBOX.L CI-B PULSE SENSOR EU868

PULSE SENSOR

Made by
Solvera Lynx is a certified partner.
Contact this partner →

Description

Key features highlights :

  • Connect two input for two pulse meters
  • Battery powered device with long autonomy
  • Collect data from different meters such as Electricity or Gas or Water equipped with a pulse output
  • Fit to industrial environment IP 67 protection
  • Data accuracy for smart metering and energy management
  • Long range capacity due to external antenna
  • Exist in Atex version see other products
  • Tampering detection in case of cable disruption
  • Data logging, time synchronization, remote configuration
  • Certified LoRaWAN® 1.0.1
# Agriculture
# End Device
# EU 863-870
# Industrial IoT
# Logistics
# LoRaWAN Certified
# Outdoor
# Smart Building
# Smart Metering

Specifications

PULSE SENSOR (ComBox.L CI) can be used with any meter with a pulse signal output (such as electricity, gas, water, heat). It provides comprehensive data to meet the needs of meter management and consumption monitoring. Pulses can be aggregated from 1 minute intervals. It can connect up to 2 meters, both connections have tampering detection. ComBox.L range is LoRaWAN certified due to their external antenna and their industrial design they have high sensitivity of connectivity and allows installation in any harsh environment.

Technical details

  • Seller SKU: ComBox.L CI-B, pulse sensor (868Mh)
  • Product Attributes: Modules, Metering, Bridges
  • Radio Frequency Band: EU868 - Europe 863-870MHz
  • LoRa Class; Class B
  • Solution Represented: Smart Agriculture, Smart Cities, Energy and Utilities, Smart Industries, Facilities Management, Other, Smart Operations, Smart Building, Smart Metering
  • Battery specification (Wh): 2 x 2600 mAh
  • Battery type: Non Rechargeable Lithium metal
  • Antenna: External on connector
  • RF transceiver: SX1276
  • Interfaces: Analog
  • Dimensions:
    • Depth (cm) 9.1
    • Width (cm) 4,26
    • Height (cm) 20.14
