COMBOX.L LPG-B ATEX LPG LEVEL SENSOR EU868

ComBox.L® ATEX are remote telemetry devices used for transmission of data from sensors and actuators to a cloud server via wireless communication with LoRa modulation. The equipment has long battery lifetime and suitable for harsh industrial environments. It is a cost-effective solution for remote monitoring, integrated with fully customised data logging and time synchronisation functionalities. The devices have been thoroughly tested; they meet safety requirements and can operate in high-risk industrial conditions.

ComBox.L®- 02 ATEX (LPG LEVEL SENSOR). It is used with a Rochester Hall effect gauge to measure the liquefied gas level in gas storage tanks located inside ATEX Zone 1 and ATEX Zone 2. Measurements are taken at preset intervals.

Key features highlights :

ComBox.L O2-Atex Rochester sensors
Connect one LPG Rochester sensor input meter and one tempering
Battery powered device with long autonomy
Collect data from Rochester sensor to measure volume level of LPG tank in ATex environment
Fit to industrial environment IP 67 protection
Data accuracy for smart metering and energy management
Long range capacity due to external antenna
Atex certified Zone 1 & 2 (II 2G Ex ib [ib] IIB T4 Gb)
Tampering detection in case of cable disruption
Data logging, time synchronization, remote configuration
Certified LoRaWAN® 1.0.1

1. RADIO
   • Frequency: 868 MHz
   • Modulation: LoRa
   • Max. wireless power:14 dBm

2. INPUT
   • No. of digital inputs: 1 (potential free contact)
   • No. of analog inputs: 1 (Hall Effect Sensor)

3. POWER
   • Battery: 2x lithium-thionyl chloride (Li-SOCl2)
   • Battery Voltage: 3,6 V (nominal)
   • Battery Capacity: 2600 mAh per battery
   • Battery manufacturer: SAFT (LS14500Ex)

4. TEMPERATURE
   • Max amb. temperature: from -20 °C to +60 °C

5. HOUSING
   • Dimensions: 200 x 90 x 43 mm
   • Weight: 280 g
   • IP Protection: IP67 (IEC 60529)
