Sensor data are transmitted in real-time using LoRaWAN® radio technology. LoRaWAN® enables encrypted radio transmissions over long distances while consuming very little power. The user can obtain sensor data through Decentlab’s data storage and visualization system, or through the user's own infrastructure.
Visit www.decentlab.com for more information about Decentlab's data cloud service.
APPLICATIONS
Cold chain
Storage
Building automation
Smart agriculture
#
End Device
#
EU 863-870
#
US 902-928
Specifications
TEMPERATURE
Range: -40 ... +125 °C
Resolution: 0.01 °C
Accuracy: ±0.1 °C from 20 … 60 °C, ±0.2 °C from -40 … 90 °C
RELATIVE HUMIDITY
Range: 0 … 100% RH
Resolution: 0.01% RH
Accuracy: ±1.5% RH from 0 … 80% RH, ±2% RH from 80 … 100% RH
Technical details
LoRaWAN™ class A
2 C alkaline batteries
13.5 cm × 8.1 cm × 7 cm (not including sensor and radiation shield)
2 m cable
Reference DL-SHT35-002
Datasheet and decoder on www.decentlab.com/support
