Loadsensing LS-G6 Wireless Data Logger

Wireless data logger

Made by
Specto Technology is a certified partner.
Contact this partner →

Description

Specto Technology is a knowledgeable expert on Loadsensing products and is proud to provide you with:

  • LS-G6 wireless data logger sales and support
  • Installation training for you and/or your sub-contractors
  • Post-purchase customer support

The Loadsensing LS-G6 Wireless Data Acquisition System Advantages:

  • Loadsensing is a long-range wifi data acquisition system for sensor networks. It delivers periodic readings for monitoring the real-time evolution of structures.
  • Loadsensing wifi data loggers are adaptable to the most commonly used sensors within the industry.

Loadsensing’s (LS) G6 industrial data logger kit is a point-to-point wireless data acquisition system for analogue, vibrating wire and digital sensors. It can be used to monitor things like inclination, strain, load, displacement, crack aperture, vibration, deformation, water level, pore pressure, water quality, hydrocarbon detection, temperature etc.

Each Wireless Monitoring System consists of one Gateway and up to hundreds of Nodes. It is the perfect monitoring solution for harsh environments or difficult-to-access sites. It allows remote monitoring to be done from the comfort of your office.

# Developement Kit
# Environment Monitoring
# Industrial IoT
# Logistics
# Platform
# Smart City
# US 902-928

Specifications

PRODUCT FEATURES:

  • Built-in Ethernet port in Gateway to connect to the Internet via LAN or external IP modem
  • Built-in radio in Gateway and Nodes for license and fee free communication
  • Optional WiFi Access Point (AP) in Gateway for connection to mobile devices such as laptop, smart phone or tablet
  • Optional GSM modem in Gateway to connect to the mobile data network
  • The Gateway can store data locally, sync with a cloud memory and perform periodic analysis of the network health
  • Each node can take readings from up to 4 x analogue sensors or 5 x VW sensors
  • Nodes have extremely low power consumption with up to 5-year battery life
  • The communication range between LS nodes is up to 10,000 ft (3km) in line-of-sight
  • The system is controlled using the web based software that resides in the Gateway or on the LS web portal. All you need is a browser to run the software
  • Rugged and reliable radio network that is very easy to set up and to deploy

To view more information on Loadsensing products click here.
