LoRa 2 click

#Click board, #LoRaWAN, #915MHz, #Industrial

Made by
Mikroe is a certified partner.

Description

LoRa 2 click is a LoRa® RF technology based SRD transceiver, which operates at a sub-gigahertz frequency of 915MHz. This click board™ features an embedded LoRaWAN™ Class A compliant stack, providing a long-range spread spectrum communication, with high interference immunity. The LoRa module used on this Click board™ is compliant with the United States (FCC) and Canada (IC) regulations, which combined with the advanced and simple command interface, allows for an easy integration into the final application, reducing development time, costs, and time to market.

# Developement Kit
# Industrial IoT
# US 902-928

Specifications

Type: LoRa,RF Sub 1GHz
Applications: Automated Meter Reading, Home and Building Automation, M2M, IoT, Industrial Monitoring and Control
On-board modules: Microchip’s RN2903 915 MHz Radio Modem
Key Features: Modem is compliant for use in USA (FCC), Canada (IC), Australia and New Zealand. Sensitivity: -146 dBm. Embeds LoRaWAN™ Class A protocol stack
Key Benefits: Less than 15 km range (rural and suburban); Less than 5 km (urban)
Interface: UART
Input Voltage: 3.3V or 5V
Compatibility: mikroBUS
Click board size: L (57.15 x 25.4 mm)

Technical details

The main active element of the LoRa 2 click the RN2903, low-power long range LoRa® technology transceiver module, from Microchip. It features the Class A LoRaWAN compliant stack, optimized for a robust LoRaWAN networking, immune to interferences, and suitable for the long-range wireless operation. It offers a long-range spread spectrum communication with high interference immunity. A receiver with the sensitivity of -146dBm combined with the 18.5dBm integrated amplifier allows for extended range links that can achieve up to 15km in open area (by the module manufacturer specification). LoRa 2 click offers data rates of 300 kbps with FSK modulation and 12500 bps with LoRa Technology modulation.
