OneSense Pulse and Current

Compact battery-powered wireless data acquisition transmitter

Made by
Evvos is a certified partner.
Contact this partner →

Description

  • Plug’n’Play – connect sensor, turn device on and start receiving sensor data2 x analog inputs + 1 x discrete/pulse counter input
  • Analog input: 4-20mA / 0-20mA / 2-10mA
  • Discrete input, dry contact, open-drain output, and pulse counter – logic level (TTL/CMOS) compatible
  • Rechargeable batteries-2 X Li-Ion batteries, type 18650, 3.7V, total capacity 5800 mAh
  • Resolution 12-bit / 16-bit
  • Ingress protection class IP66
  • Operation temperature range -20 °C to +70 °C# AU 915-928

EU 863-870# US 902-928

# Agriculture
# End Device
# EU 863-870
# Industrial IoT
# US 902-928

Specifications

OneSense is a compact cost-effective, battery-powered wireless data acquisition product line. It is designed for a wide range of industrial, environmental and agricultural applications. To help you reduce your cost per sensing point, Evvos has developed advanced interface circuitries which allow you to connect up to 3 sensors/probes to a single OneSense device. All OneSense product versions have multiple power supply options to further lower maintenance costs and to provide you with just enough flexibility to address the needs of your business.

Collected sensor data is transmitted wirelessly through LoRaWAN.
Please supply external power to sensor if you plan on using 4-20mA / 0-20mA / 2-10mA interface or ask for an external power add-on board.

Typical Applications:
- Industrial Monitoring
- Building Automation
- Agriculture
