Oudoor Gateway GW300

868MHz terminal

Made by
Friendcom is a certified partner.
Contact this partner →

Description

The GW300 is a LoRaWAN outdoor industrial grade IoT gateway designed for IoT and M2M applications. It features a high-performance 1.2GHz frequency ARM Cortex-A53 core and integrates Semtech's high-performance SX1301 LoRa baseband processing chip. The gateway adopts POE power supply mode and can connect to LoRaWAN cloud server through Ethernet and 2/3/4G connections and support GPS positioning function

# EU 863-870
# Gateways
# Outdoor

Specifications

High performance: Maximum transmit power up to 27dBm, receiving sensitivity of -141dBm@300bps LoRaWAN uplink: 8 parallel Multi-SF LoRa channels, 1 Single-SF LoRa Channel, 1 high-speed GFSK channel LoRaWAN downlink: 1 normal channel (125kHz / 250kHz / 500kHz bandwidth) Supports LoRaWAN communication half duplex mode Supports PoE power supply, conforms to PoE IEEE802.3 af/at standard, PoE power supplied within 100m Supports 10/100 M Ethernet and 2G/3G/4G full Netcom connections and supports seamless switching IP66 waterproof rating, can be easily installed outdoors or in complex environment, and networking easily Seamless connection LoRaWAN cloud platform

Oudoor Gateway GW300's Distributors
Friendcom

Provider of wireless M2M solutions
