SenseCAP LoRaWAN Light Intensity Sensor

Smart Agriculture, Precision Agriculture, Environmental Monitoring, Outdoor, Industrial IoT

Made by
SEEED Studio is a certified partner.

Description

With a built-in wireless LoRa module, SenseCAP LoRaWAN Light Intensity Sensor transmits the collected light data to the base station and then to the server. Based on an ultra-low-power light-sensing chip, it supports a super-wide measurement range of 22 bits, applicable for industrial environmental sensing.

# Agriculture
# CN 470-510
# End Device
# Environment Monitoring
# Indoor
# Industrial IoT
# Logistics
# Outdoor
# US 902-928

Specifications

  • Light IntensityRange: 0 to 188000 LuxSensitivity: 0.045 Lux/LSBResolution: 0.045 Lux
  • Microcontroller: Ultra-low-power MCU
  • Support Protocol: Based on LoRaWAN v1.0.2 protocol
  • LoRa Channel Plan: CN470 / EU868 / US915
  • LoRa Power Output: 16dBm (EIRP)
  • Sensitivity: 470MHz: -140dBm(SF12, BW125KHz);868MHz: -137.5dBm(SF12, BW125KHz);915MHz: -136.5dBm(SF12, BW125KHz)
  • Current Consumption: 5 μA (sleep mode);120 mA (active mode)
  • Communication Distance: 2 to 10 km (depending on different antennas and environments)

Technical details

  • Certifications: CE, FCC, RoHS, LoRaWAN Certified
  • IP Rating: IP66
  • Battery Life: ≥ 3 years (upload data once per hour)
  • Battery Voltage: 3.6V
  • Battery Capacity: 19Ah (Non-rechargeable)
  • UV Resistance: anti-aging (from rain/sun exposure)
  • Enclosure Material: PC
  • Operating Temperature: -40 °C to +85 °C
  • Operating Humidity: 0 to 100 %RH (non-condensing)
  • Device Weight: 288g
