Open technology for sustainable farming
Vinduino R3 Sensor Station
Vinduino Remote Sensor Station Platform for agriculture irrigation
Description
The Vinduino R3 sensor station is a solar powered remote sensor platform. It is optimized for supporting multiple soil sensors, aimed at saving irrigation water and improving crop health at lowest system cost.
This product represents the 3rd generation design of our remote sensor platform, and passed extensive agricultural field trials.
Specifications
Features
- Works with eVineyard vineyard management software
- Plug-and-play, ships pre-configured
- 4 inputs for soil moisture sensors
- LoRa wireless module included, up to 5 mile range
- Supports optional temperature/relative humidity sensors
- Solar battery charger, 3 week battery life without recharge
- Real time clock for sleep mode power saving and precise irrigation timing
- Load switch for actuators or sensors that require electric power
- NEMA 4X waterproof enclosure, 6.13 x 4.63 x 2.44 in (made in USA)
- Proudly designed and build in California
Technical details
Supported sensors
- Vinduino ceramic soil water tension sensor (4 x)
- Watermark SS200 soil water tension sensor (4 x)
- Capacitive (FDR) volumetric soil moisture sensors (3x)
- Temperature
Vinduino R3 Sensor Station's Distributors
Vinduino R3 Sensor Station is included in the following solutions
Vinduino Precision Irrigation Solution
At Vinduino we build the future of agriculture technology and increase optimized usage of scarce resources, Vinduino helps agriculture communities to better manage irrigation through open source and affordable water-saving technology.
