WISE-4610

LoRa Outdoor Wireless I/O Module

Made by
Advantech is a certified partner.
Contact this partner →

Description

LPWAN is a type of wireless telecommunication wide area network designed to allow long range communications at a low data rate among IoT applications, such as sensors operated on a battery. Its benefits is to offer multi-year battery lifetime for sensors/applications to send small amounts of data over long distances a few times per hour suitable for different environments.

LoRa and LoRaWAN are one of category of LPWAN which belong to the non-cellular LPWAN wireless communication network protocols enables very long range transmissions with low power consumption, operating in the non-licensed spectrum. What is the difference between LoRa and LoraWAN? LoRa (Long Range) is a patented wireless data communication of IoT technology and acquired by Semtech in 2012 which holds the IP for LoRa transmission methodology.

# AU 915-928
# End Device
# EU 863-870
# Indoor
# US 902-928

Specifications

  • For North America, Europe and Japan
  • Longer communication range
  • Better penetration through concrete and steel
  • Less interference than 2.4GHz spectrum
  • Application-ready I/O combination with IP65 enclosure
  • Powered by solar rechargeable battery or 10~50VDC input
  • Global Positioning System (GPS) support

Ordering Information

  • WISE-4610-S672NA LoRa Outdoor WSN with 6DI & 2COM - NA915
  • WISE-4610-S672EA LoRa Outdoor WSN with 6DI & 2COM - EU868
  • WISE-4610-S672JA LoRa Outdoor WSN with 6DI & 2COM - JP923
  • WISE-4610-S614NA LoRa Outdoor WSN with 4AI & 4DI - NA915
  • WISE-4610-S614EA LoRa Outdoor WSN with 4AI & 4DI - EU868
  • WISE-4610-S614JA LoRa Outdoor WSN with 4AI & 4DI - JP923

Technical details

Wireless Communication

  • IEEE Standard: IEEE 802.15.4g
  • Frequency Band: EU 863-870 (MHz), US 902-928 (MHz), AU (JP) 915-928 (MHz)
  • Spreading Factor: 7~12
  • Outdoor Range: 5km with line of sight (with 2 dBi Antenna)
  • Transmit Power: Up to +18dBm
  • Receiver Sensitivity: Up to -136dBm at SF = 12 / 125KHz
  • Data Rate: 50 kbps at FSK mode EU868 | 21.9 kbps at SF7 mode US915 | 5.47 kbps at SF7 mode JP923
  • Topology: Star
  • Function: End Node

GPS¹

  • GNSS Systems: GPS, GLONASS, Galileo, BeiDou, QZSS and SBAS signals
  • Max. Update Rate: Single GNSS: up to 18 Hz | Concurrent GNSS: up to 10 Hz
  • Accuracy Position: 2.5 m CEP (50% confidence) | With SBAS: 2.0 m CEP (50% confidence)
  • Acquisition: Cold starts: 57 s | Aided starts: 7 s

General

  • Power Input: Built-in 4000mA Lithium rechargeable battery pack² or 10~50VDC external power
  • Battery Life: 6 months (1 hour data update and 1 day GPS update)
  • Configuration Interface: Micro-B USB
  • Connector Power: M12 4-pin code-A male x 1 | I/O: M12 8-pin code-D female x 2
  • LED Indicator: Status, Error, Tx, Rx, Battery/Signal Level
  • Mounting DIN 35 rail, wall, pole, and stack
  • Dimension (W x H x D): 82 x 122 x 49 mm (without antenna)

Environment

  • Operating Temperature²: 0~60°C | No Battery Version: -20~70°C
  • Operating Humidity: 5~95% RH

¹ No GPS version, can be order by request
² No battery version, can be order by request

Serial Port

  • Port Number: 2
  • Type: Port 1: RS-485 | Port 2: RS-485/232
  • Serial Signal: RS-485: DATA+, DATARS-232: Tx, Rx, GND
  • Data Bits: 7, 8
  • Stop Bits: 1, 2
  • Parity: None, Odd, Even
  • Baud Rate (bps): 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200
  • Protection: 15 kV ESD
  • Protocol: Modbus/RTU (Total 32 address)

Digital Input

  • Channels 6
  • Input Type Dry Contact (Wet Contact by request)
  • Logic Level 0: Open | 1: Close to DCOM
  • Isolation Voltage 3,000Vrms
    **- Supports 200Hz Counter Input (16-bit + 1-bit overflow)
  • Keep/Discard Counter Value when Power-off
  • Supports 200Hz Frequency Input
  • Supports Inverted DI Status**
