…and a more elegant way to set a static IP on the Beagle Bone Black/Green, without removing the ConnMan Network Manager::wink:

1. Connect working Ethernet cable on LAN port

2. Get ConnMan service name

~$ connmanctl services

*AO Wired ethernet_6ceceb5cc3e2_cable

* if you can't see "ethernet_xxx_cable", please check step 1.

3. Set static IP through ConnMan

* usage:

sudo connmanctl config <service> --ipv4 manual <ip_addr> <netmask> <gateway> --nameservers <dns_server>

~$ sudo connmanctl config ethernet_6ceceb5cc3e2_cable --ipv4 manual 10.0.10.0 255.255.0.0

4. Check eth0 configurations

~$ ifconfig eth0

~$ ip addr show dev eth0

End

*** TIP *** You can back to dhcp IP with below command.

~$ sudo connmanctl config ethernet_6ceceb5cc3e2_cable --ipv4 dhcp
