Arduino Pro Mini RFM95 pinmap problem

This is the line

Sorry, my screen reader can’t cope with images and neither can the forum. Please post text as text formatted using the </> tool. But don’t worry, I already know what’s on that line, I was wondering if you did.

But as, like others before you, I don’t see any thoughts on what it might mean.

Ok I will put the code using the </> tool. No I don’t know what exactly I’m a beginner on LMIC.
Do you have a solution for this problem

type or paste code here
/*******************************************************************************
 * Copyright (c) 2014-2015 IBM Corporation.
 * All rights reserved. This program and the accompanying materials
 * are made available under the terms of the Eclipse Public License v1.0
 * which accompanies this distribution, and is available at
 * http://www.eclipse.org/legal/epl-v10.html
 *
 * Contributors:
 *    IBM Zurich Research Lab - initial API, implementation and documentation
 *******************************************************************************/

#include "lmic.h"

// ----------------------------------------
// Registers Mapping
#define RegFifo                                    0x00 // common
#define RegOpMode                                  0x01 // common
#define FSKRegBitrateMsb                           0x02
#define FSKRegBitrateLsb                           0x03
#define FSKRegFdevMsb                              0x04
#define FSKRegFdevLsb                              0x05
#define RegFrfMsb                                  0x06 // common
#define RegFrfMid                                  0x07 // common
#define RegFrfLsb                                  0x08 // common
#define RegPaConfig                                0x09 // common
#define RegPaRamp                                  0x0A // common
#define RegOcp                                     0x0B // common
#define RegLna                                     0x0C // common
#define FSKRegRxConfig                             0x0D
#define LORARegFifoAddrPtr                         0x0D
#define FSKRegRssiConfig                           0x0E
#define LORARegFifoTxBaseAddr                      0x0E
#define FSKRegRssiCollision                        0x0F
#define LORARegFifoRxBaseAddr                      0x0F
#define FSKRegRssiThresh                           0x10
#define LORARegFifoRxCurrentAddr                   0x10
#define FSKRegRssiValue                            0x11
#define LORARegIrqFlagsMask                        0x11
#define FSKRegRxBw                                 0x12
#define LORARegIrqFlags                            0x12
#define FSKRegAfcBw                                0x13
#define LORARegRxNbBytes                           0x13
#define FSKRegOokPeak                              0x14
#define LORARegRxHeaderCntValueMsb                 0x14
#define FSKRegOokFix                               0x15
#define LORARegRxHeaderCntValueLsb                 0x15
#define FSKRegOokAvg                               0x16
#define LORARegRxPacketCntValueMsb                 0x16
#define LORARegRxpacketCntValueLsb                 0x17
#define LORARegModemStat                           0x18
#define LORARegPktSnrValue                         0x19
#define FSKRegAfcFei                               0x1A
#define LORARegPktRssiValue                        0x1A
#define FSKRegAfcMsb                               0x1B
#define LORARegRssiValue                           0x1B
#define FSKRegAfcLsb                               0x1C
#define LORARegHopChannel                          0x1C
#define FSKRegFeiMsb                               0x1D
#define LORARegModemConfig1                        0x1D
#define FSKRegFeiLsb                               0x1E
#define LORARegModemConfig2                        0x1E
#define FSKRegPreambleDetect                       0x1F
#define LORARegSymbTimeoutLsb                      0x1F
#define FSKRegRxTimeout1                           0x20
#define LORARegPreambleMsb                         0x20
#define FSKRegRxTimeout2                           0x21
#define LORARegPreambleLsb                         0x21
#define FSKRegRxTimeout3                           0x22
#define LORARegPayloadLength                       0x22
#define FSKRegRxDelay                              0x23
#define LORARegPayloadMaxLength                    0x23
#define FSKRegOsc                                  0x24
#define LORARegHopPeriod                           0x24
#define FSKRegPreambleMsb                          0x25
#define LORARegFifoRxByteAddr                      0x25
#define LORARegModemConfig3                        0x26
#define FSKRegPreambleLsb                          0x26
#define FSKRegSyncConfig                           0x27
#define LORARegFeiMsb                              0x28
#define FSKRegSyncValue1                           0x28
#define LORAFeiMib                                 0x29
#define FSKRegSyncValue2                           0x29
#define LORARegFeiLsb                              0x2A
#define FSKRegSyncValue3                           0x2A
#define FSKRegSyncValue4                           0x2B
#define LORARegRssiWideband                        0x2C
#define FSKRegSyncValue5                           0x2C
#define FSKRegSyncValue6                           0x2D
#define FSKRegSyncValue7                           0x2E
#define FSKRegSyncValue8                           0x2F
#define FSKRegPacketConfig1                        0x30
#define FSKRegPacketConfig2                        0x31
#define LORARegDetectOptimize                      0x31
#define FSKRegPayloadLength                        0x32
#define FSKRegNodeAdrs                             0x33
#define LORARegInvertIQ                            0x33
#define FSKRegBroadcastAdrs                        0x34
#define FSKRegFifoThresh                           0x35
#define FSKRegSeqConfig1                           0x36
#define FSKRegSeqConfig2                           0x37
#define LORARegDetectionThreshold                  0x37
#define FSKRegTimerResol                           0x38
#define FSKRegTimer1Coef                           0x39
#define LORARegSyncWord                            0x39
#define FSKRegTimer2Coef                           0x3A
#define FSKRegImageCal                             0x3B
#define FSKRegTemp                                 0x3C
#define FSKRegLowBat                               0x3D
#define FSKRegIrqFlags1                            0x3E
#define FSKRegIrqFlags2                            0x3F
#define RegDioMapping1                             0x40 // common
#define RegDioMapping2                             0x41 // common
#define RegVersion                                 0x42 // common
// #define RegAgcRef                                  0x43 // common
// #define RegAgcThresh1                              0x44 // common
// #define RegAgcThresh2                              0x45 // common
// #define RegAgcThresh3                              0x46 // common
// #define RegPllHop                                  0x4B // common
// #define RegTcxo                                    0x58 // common
#define RegPaDac                                   0x5A // common
// #define RegPll                                     0x5C // common
// #define RegPllLowPn                                0x5E // common
// #define RegFormerTemp                              0x6C // common
// #define RegBitRateFrac                             0x70 // common

// ----------------------------------------
// spread factors and mode for RegModemConfig2
#define SX1272_MC2_FSK  0x00
#define SX1272_MC2_SF7  0x70
#define SX1272_MC2_SF8  0x80
#define SX1272_MC2_SF9  0x90
#define SX1272_MC2_SF10 0xA0
#define SX1272_MC2_SF11 0xB0
#define SX1272_MC2_SF12 0xC0
// bandwidth for RegModemConfig1
#define SX1272_MC1_BW_125  0x00
#define SX1272_MC1_BW_250  0x40
#define SX1272_MC1_BW_500  0x80
// coding rate for RegModemConfig1
#define SX1272_MC1_CR_4_5 0x08
#define SX1272_MC1_CR_4_6 0x10
#define SX1272_MC1_CR_4_7 0x18
#define SX1272_MC1_CR_4_8 0x20
#define SX1272_MC1_IMPLICIT_HEADER_MODE_ON 0x04 // required for receive
#define SX1272_MC1_RX_PAYLOAD_CRCON        0x02
#define SX1272_MC1_LOW_DATA_RATE_OPTIMIZE  0x01 // mandated for SF11 and SF12
// transmit power configuration for RegPaConfig
#define SX1272_PAC_PA_SELECT_PA_BOOST 0x80
#define SX1272_PAC_PA_SELECT_RFIO_PIN 0x00


// sx1276 RegModemConfig1
#define SX1276_MC1_BW_125                0x70
#define SX1276_MC1_BW_250                0x80
#define SX1276_MC1_BW_500                0x90
#define SX1276_MC1_CR_4_5            0x02
#define SX1276_MC1_CR_4_6            0x04
#define SX1276_MC1_CR_4_7            0x06
#define SX1276_MC1_CR_4_8            0x08

#define SX1276_MC1_IMPLICIT_HEADER_MODE_ON    0x01

// sx1276 RegModemConfig2
#define SX1276_MC2_RX_PAYLOAD_CRCON        0x04

// sx1276 RegModemConfig3
#define SX1276_MC3_LOW_DATA_RATE_OPTIMIZE  0x08
#define SX1276_MC3_AGCAUTO                 0x04

// preamble for lora networks (nibbles swapped)
#define LORA_MAC_PREAMBLE                  0x34

#define RXLORA_RXMODE_RSSI_REG_MODEM_CONFIG1 0x0A
#ifdef CFG_sx1276_radio
#define RXLORA_RXMODE_RSSI_REG_MODEM_CONFIG2 0x70
#elif CFG_sx1272_radio
#define RXLORA_RXMODE_RSSI_REG_MODEM_CONFIG2 0x74
#endif



// ----------------------------------------
// Constants for radio registers
#define OPMODE_LORA      0x80
#define OPMODE_MASK      0x07
#define OPMODE_SLEEP     0x00
#define OPMODE_STANDBY   0x01
#define OPMODE_FSTX      0x02
#define OPMODE_TX        0x03
#define OPMODE_FSRX      0x04
#define OPMODE_RX        0x05
#define OPMODE_RX_SINGLE 0x06
#define OPMODE_CAD       0x07

// ----------------------------------------
// Bits masking the corresponding IRQs from the radio
#define IRQ_LORA_RXTOUT_MASK 0x80
#define IRQ_LORA_RXDONE_MASK 0x40
#define IRQ_LORA_CRCERR_MASK 0x20
#define IRQ_LORA_HEADER_MASK 0x10
#define IRQ_LORA_TXDONE_MASK 0x08
#define IRQ_LORA_CDDONE_MASK 0x04
#define IRQ_LORA_FHSSCH_MASK 0x02
#define IRQ_LORA_CDDETD_MASK 0x01

#define IRQ_FSK1_MODEREADY_MASK         0x80
#define IRQ_FSK1_RXREADY_MASK           0x40
#define IRQ_FSK1_TXREADY_MASK           0x20
#define IRQ_FSK1_PLLLOCK_MASK           0x10
#define IRQ_FSK1_RSSI_MASK              0x08
#define IRQ_FSK1_TIMEOUT_MASK           0x04
#define IRQ_FSK1_PREAMBLEDETECT_MASK    0x02
#define IRQ_FSK1_SYNCADDRESSMATCH_MASK  0x01
#define IRQ_FSK2_FIFOFULL_MASK          0x80
#define IRQ_FSK2_FIFOEMPTY_MASK         0x40
#define IRQ_FSK2_FIFOLEVEL_MASK         0x20
#define IRQ_FSK2_FIFOOVERRUN_MASK       0x10
#define IRQ_FSK2_PACKETSENT_MASK        0x08
#define IRQ_FSK2_PAYLOADREADY_MASK      0x04
#define IRQ_FSK2_CRCOK_MASK             0x02
#define IRQ_FSK2_LOWBAT_MASK            0x01

// ----------------------------------------
// DIO function mappings                D0D1D2D3
#define MAP_DIO0_LORA_RXDONE   0x00  // 00------
#define MAP_DIO0_LORA_TXDONE   0x40  // 01------
#define MAP_DIO1_LORA_RXTOUT   0x00  // --00----
#define MAP_DIO1_LORA_NOP      0x30  // --11----
#define MAP_DIO2_LORA_NOP      0xC0  // ----11--

#define MAP_DIO0_FSK_READY     0x00  // 00------ (packet sent / payload ready)
#define MAP_DIO1_FSK_NOP       0x30  // --11----
#define MAP_DIO2_FSK_TXNOP     0x04  // ----01--
#define MAP_DIO2_FSK_TIMEOUT   0x08  // ----10--


// FSK IMAGECAL defines
#define RF_IMAGECAL_AUTOIMAGECAL_MASK               0x7F
#define RF_IMAGECAL_AUTOIMAGECAL_ON                 0x80
#define RF_IMAGECAL_AUTOIMAGECAL_OFF                0x00  // Default

#define RF_IMAGECAL_IMAGECAL_MASK                   0xBF
#define RF_IMAGECAL_IMAGECAL_START                  0x40

#define RF_IMAGECAL_IMAGECAL_RUNNING                0x20
#define RF_IMAGECAL_IMAGECAL_DONE                   0x00  // Default


// RADIO STATE
// (initialized by radio_init(), used by radio_rand1())
static u1_t randbuf[16];


#ifdef CFG_sx1276_radio
#define LNA_RX_GAIN (0x20|0x1)
#elif CFG_sx1272_radio
#define LNA_RX_GAIN (0x20|0x03)
#else
#error Missing CFG_sx1272_radio/CFG_sx1276_radio
#endif


static void writeReg (u1_t addr, u1_t data ) {
    hal_pin_nss(0);
    hal_spi(addr | 0x80);
    hal_spi(data);
    hal_pin_nss(1);
}

static u1_t readReg (u1_t addr) {
    hal_pin_nss(0);
    hal_spi(addr & 0x7F);
    u1_t val = hal_spi(0x00);
    hal_pin_nss(1);
    return val;
}

static void writeBuf (u1_t addr, xref2u1_t buf, u1_t len) {
    hal_pin_nss(0);
    hal_spi(addr | 0x80);
    for (u1_t i=0; i<len; i++) {
        hal_spi(buf[i]);
    }
    hal_pin_nss(1);
}

static void readBuf (u1_t addr, xref2u1_t buf, u1_t len) {
    hal_pin_nss(0);
    hal_spi(addr & 0x7F);
    for (u1_t i=0; i<len; i++) {
        buf[i] = hal_spi(0x00);
    }
    hal_pin_nss(1);
}

static void opmode (u1_t mode) {
    writeReg(RegOpMode, (readReg(RegOpMode) & ~OPMODE_MASK) | mode);
}

static void opmodeLora() {
    u1_t u = OPMODE_LORA;
#ifdef CFG_sx1276_radio
    u |= 0x8;   // TBD: sx1276 high freq
#endif
    writeReg(RegOpMode, u);
}

static void opmodeFSK() {
    u1_t u = 0;
#ifdef CFG_sx1276_radio
    u |= 0x8;   // TBD: sx1276 high freq
#endif
    writeReg(RegOpMode, u);
}

// configure LoRa modem (cfg1, cfg2)
static void configLoraModem () {
    sf_t sf = getSf(LMIC.rps);

#ifdef CFG_sx1276_radio
        u1_t mc1 = 0, mc2 = 0, mc3 = 0;

        switch (getBw(LMIC.rps)) {
        case BW125: mc1 |= SX1276_MC1_BW_125; break;
        case BW250: mc1 |= SX1276_MC1_BW_250; break;
        case BW500: mc1 |= SX1276_MC1_BW_500; break;
        default:
            ASSERT(0);
        }
        switch( getCr(LMIC.rps) ) {
        case CR_4_5: mc1 |= SX1276_MC1_CR_4_5; break;
        case CR_4_6: mc1 |= SX1276_MC1_CR_4_6; break;
        case CR_4_7: mc1 |= SX1276_MC1_CR_4_7; break;
        case CR_4_8: mc1 |= SX1276_MC1_CR_4_8; break;
        default:
            ASSERT(0);
        }

        if (getIh(LMIC.rps)) {
            mc1 |= SX1276_MC1_IMPLICIT_HEADER_MODE_ON;
            writeReg(LORARegPayloadLength, getIh(LMIC.rps)); // required length
        }
        // set ModemConfig1
        writeReg(LORARegModemConfig1, mc1);

        mc2 = (SX1272_MC2_SF7 + ((sf-1)<<4));
        if (getNocrc(LMIC.rps) == 0) {
            mc2 |= SX1276_MC2_RX_PAYLOAD_CRCON;
        }
        writeReg(LORARegModemConfig2, mc2);

        mc3 = SX1276_MC3_AGCAUTO;
        if ((sf == SF11 || sf == SF12) && getBw(LMIC.rps) == BW125) {
            mc3 |= SX1276_MC3_LOW_DATA_RATE_OPTIMIZE;
        }
        writeReg(LORARegModemConfig3, mc3);
#elif CFG_sx1272_radio
        u1_t mc1 = (getBw(LMIC.rps)<<6);

        switch( getCr(LMIC.rps) ) {
        case CR_4_5: mc1 |= SX1272_MC1_CR_4_5; break;
        case CR_4_6: mc1 |= SX1272_MC1_CR_4_6; break;
        case CR_4_7: mc1 |= SX1272_MC1_CR_4_7; break;
        case CR_4_8: mc1 |= SX1272_MC1_CR_4_8; break;
        }

        if ((sf == SF11 || sf == SF12) && getBw(LMIC.rps) == BW125) {
            mc1 |= SX1272_MC1_LOW_DATA_RATE_OPTIMIZE;
        }

        if (getNocrc(LMIC.rps) == 0) {
            mc1 |= SX1272_MC1_RX_PAYLOAD_CRCON;
        }

        if (getIh(LMIC.rps)) {
            mc1 |= SX1272_MC1_IMPLICIT_HEADER_MODE_ON;
            writeReg(LORARegPayloadLength, getIh(LMIC.rps)); // required length
        }
        // set ModemConfig1
        writeReg(LORARegModemConfig1, mc1);

        // set ModemConfig2 (sf, AgcAutoOn=1 SymbTimeoutHi=00)
        writeReg(LORARegModemConfig2, (SX1272_MC2_SF7 + ((sf-1)<<4)) | 0x04);
#else
#error Missing CFG_sx1272_radio/CFG_sx1276_radio
#endif /* CFG_sx1272_radio */
}

static void configChannel () {
    // set frequency: FQ = (FRF * 32 Mhz) / (2 ^ 19)
    uint64_t frf = ((uint64_t)LMIC.freq << 19) / 32000000;
    writeReg(RegFrfMsb, (u1_t)(frf>>16));
    writeReg(RegFrfMid, (u1_t)(frf>> 8));
    writeReg(RegFrfLsb, (u1_t)(frf>> 0));
}



static void configPower () {
#ifdef CFG_sx1276_radio
    // no boost used for now
    s1_t pw = (s1_t)LMIC.txpow;
    if(pw >= 17) {
        pw = 15;
    } else if(pw < 2) {
        pw = 2;
    }
    // check board type for BOOST pin
    writeReg(RegPaConfig, (u1_t)(0x80|(pw&0xf)));
    writeReg(RegPaDac, readReg(RegPaDac)|0x4);

#elif CFG_sx1272_radio
    // set PA config (2-17 dBm using PA_BOOST)
    s1_t pw = (s1_t)LMIC.txpow;
    if(pw > 17) {
        pw = 17;
    } else if(pw < 2) {
        pw = 2;
    }
    writeReg(RegPaConfig, (u1_t)(0x80|(pw-2)));
#else
#error Missing CFG_sx1272_radio/CFG_sx1276_radio
#endif /* CFG_sx1272_radio */
}

static void txfsk () {
    // select FSK modem (from sleep mode)
    writeReg(RegOpMode, 0x10); // FSK, BT=0.5
    ASSERT(readReg(RegOpMode) == 0x10);
    // enter standby mode (required for FIFO loading))
    opmode(OPMODE_STANDBY);
    // set bitrate
    writeReg(FSKRegBitrateMsb, 0x02); // 50kbps
    writeReg(FSKRegBitrateLsb, 0x80);
    // set frequency deviation
    writeReg(FSKRegFdevMsb, 0x01); // +/- 25kHz
    writeReg(FSKRegFdevLsb, 0x99);
    // frame and packet handler settings
    writeReg(FSKRegPreambleMsb, 0x00);
    writeReg(FSKRegPreambleLsb, 0x05);
    writeReg(FSKRegSyncConfig, 0x12);
    writeReg(FSKRegPacketConfig1, 0xD0);
    writeReg(FSKRegPacketConfig2, 0x40);
    writeReg(FSKRegSyncValue1, 0xC1);
    writeReg(FSKRegSyncValue2, 0x94);
    writeReg(FSKRegSyncValue3, 0xC1);
    // configure frequency
    configChannel();
    // configure output power
    configPower();

    // set the IRQ mapping DIO0=PacketSent DIO1=NOP DIO2=NOP
    writeReg(RegDioMapping1, MAP_DIO0_FSK_READY|MAP_DIO1_FSK_NOP|MAP_DIO2_FSK_TXNOP);

    // initialize the payload size and address pointers
    writeReg(FSKRegPayloadLength, LMIC.dataLen+1); // (insert length byte into payload))

    // download length byte and buffer to the radio FIFO
    writeReg(RegFifo, LMIC.dataLen);
    writeBuf(RegFifo, LMIC.frame, LMIC.dataLen);

    // enable antenna switch for TX
    hal_pin_rxtx(1);

    // now we actually start the transmission
    opmode(OPMODE_TX);
}

static void txlora () {
    // select LoRa modem (from sleep mode)
    //writeReg(RegOpMode, OPMODE_LORA);
    opmodeLora();
    ASSERT((readReg(RegOpMode) & OPMODE_LORA) != 0);

    // enter standby mode (required for FIFO loading))
    opmode(OPMODE_STANDBY);
    // configure LoRa modem (cfg1, cfg2)
    configLoraModem();
    // configure frequency
    configChannel();
    // configure output power
    writeReg(RegPaRamp, (readReg(RegPaRamp) & 0xF0) | 0x08); // set PA ramp-up time 50 uSec
    configPower();
    // set sync word
    writeReg(LORARegSyncWord, LORA_MAC_PREAMBLE);

    // set the IRQ mapping DIO0=TxDone DIO1=NOP DIO2=NOP
    writeReg(RegDioMapping1, MAP_DIO0_LORA_TXDONE|MAP_DIO1_LORA_NOP|MAP_DIO2_LORA_NOP);
    // clear all radio IRQ flags
    writeReg(LORARegIrqFlags, 0xFF);
    // mask all IRQs but TxDone
    writeReg(LORARegIrqFlagsMask, ~IRQ_LORA_TXDONE_MASK);

    // initialize the payload size and address pointers
    writeReg(LORARegFifoTxBaseAddr, 0x00);
    writeReg(LORARegFifoAddrPtr, 0x00);
    writeReg(LORARegPayloadLength, LMIC.dataLen);

    // download buffer to the radio FIFO
    writeBuf(RegFifo, LMIC.frame, LMIC.dataLen);

    // enable antenna switch for TX
    hal_pin_rxtx(1);

    // now we actually start the transmission
    opmode(OPMODE_TX);

#if LMIC_DEBUG_LEVEL > 0
    u1_t sf = getSf(LMIC.rps) + 6; // 1 == SF7
    u1_t bw = getBw(LMIC.rps);
    u1_t cr = getCr(LMIC.rps);
    lmic_printf("%lu: TXMODE, freq=%lu, len=%d, SF=%d, BW=%d, CR=4/%d, IH=%d\n",
           os_getTime(), LMIC.freq, LMIC.dataLen, sf,
           bw == BW125 ? 125 : (bw == BW250 ? 250 : 500),
           cr == CR_4_5 ? 5 : (cr == CR_4_6 ? 6 : (cr == CR_4_7 ? 7 : 8)),
           getIh(LMIC.rps)
   );
#endif
}

// start transmitter (buf=LMIC.frame, len=LMIC.dataLen)
static void starttx () {
    ASSERT( (readReg(RegOpMode) & OPMODE_MASK) == OPMODE_SLEEP );
    if(getSf(LMIC.rps) == FSK) { // FSK modem
        txfsk();
    } else { // LoRa modem
        txlora();
    }
    // the radio will go back to STANDBY mode as soon as the TX is finished
    // the corresponding IRQ will inform us about completion.
}

enum { RXMODE_SINGLE, RXMODE_SCAN, RXMODE_RSSI };

static CONST_TABLE(u1_t, rxlorairqmask)[] = {
    [RXMODE_SINGLE] = IRQ_LORA_RXDONE_MASK|IRQ_LORA_RXTOUT_MASK,
    [RXMODE_SCAN]   = IRQ_LORA_RXDONE_MASK,
    [RXMODE_RSSI]   = 0x00,
};

// start LoRa receiver (time=LMIC.rxtime, timeout=LMIC.rxsyms, result=LMIC.frame[LMIC.dataLen])
static void rxlora (u1_t rxmode) {
    // select LoRa modem (from sleep mode)
    opmodeLora();
    ASSERT((readReg(RegOpMode) & OPMODE_LORA) != 0);
    // enter standby mode (warm up))
    opmode(OPMODE_STANDBY);
    // don't use MAC settings at startup
    if(rxmode == RXMODE_RSSI) { // use fixed settings for rssi scan
        writeReg(LORARegModemConfig1, RXLORA_RXMODE_RSSI_REG_MODEM_CONFIG1);
        writeReg(LORARegModemConfig2, RXLORA_RXMODE_RSSI_REG_MODEM_CONFIG2);
    } else { // single or continuous rx mode
        // configure LoRa modem (cfg1, cfg2)
        configLoraModem();
        // configure frequency
        configChannel();
    }
    // set LNA gain
    writeReg(RegLna, LNA_RX_GAIN);
    // set max payload size
    writeReg(LORARegPayloadMaxLength, 64);
#if !defined(DISABLE_INVERT_IQ_ON_RX)
    // use inverted I/Q signal (prevent mote-to-mote communication)
    writeReg(LORARegInvertIQ, readReg(LORARegInvertIQ)|(1<<6));
#endif
    // set symbol timeout (for single rx)
    writeReg(LORARegSymbTimeoutLsb, LMIC.rxsyms);
    // set sync word
    writeReg(LORARegSyncWord, LORA_MAC_PREAMBLE);

    // configure DIO mapping DIO0=RxDone DIO1=RxTout DIO2=NOP
    writeReg(RegDioMapping1, MAP_DIO0_LORA_RXDONE|MAP_DIO1_LORA_RXTOUT|MAP_DIO2_LORA_NOP);
    // clear all radio IRQ flags
    writeReg(LORARegIrqFlags, 0xFF);
    // enable required radio IRQs
    writeReg(LORARegIrqFlagsMask, ~TABLE_GET_U1(rxlorairqmask, rxmode));

    // enable antenna switch for RX
    hal_pin_rxtx(0);

    // now instruct the radio to receive
    if (rxmode == RXMODE_SINGLE) { // single rx
        hal_waitUntil(LMIC.rxtime); // busy wait until exact rx time
        opmode(OPMODE_RX_SINGLE);
    } else { // continous rx (scan or rssi)
        opmode(OPMODE_RX);
    }

#if LMIC_DEBUG_LEVEL > 0
    if (rxmode == RXMODE_RSSI) {
        lmic_printf("RXMODE_RSSI\n");
    } else {
        u1_t sf = getSf(LMIC.rps) + 6; // 1 == SF7
        u1_t bw = getBw(LMIC.rps);
        u1_t cr = getCr(LMIC.rps);
        lmic_printf("%lu: %s, freq=%lu, SF=%d, BW=%d, CR=4/%d, IH=%d\n",
               os_getTime(),
               rxmode == RXMODE_SINGLE ? "RXMODE_SINGLE" : (rxmode == RXMODE_SCAN ? "RXMODE_SCAN" : "UNKNOWN_RX"),
               LMIC.freq, sf,
               bw == BW125 ? 125 : (bw == BW250 ? 250 : 500),
               cr == CR_4_5 ? 5 : (cr == CR_4_6 ? 6 : (cr == CR_4_7 ? 7 : 8)),
               getIh(LMIC.rps)
       );
    }
#endif
}

static void rxfsk (u1_t rxmode) {
    // only single rx (no continuous scanning, no noise sampling)
    ASSERT( rxmode == RXMODE_SINGLE );
    // select FSK modem (from sleep mode)
    //writeReg(RegOpMode, 0x00); // (not LoRa)
    opmodeFSK();
    ASSERT((readReg(RegOpMode) & OPMODE_LORA) == 0);
    // enter standby mode (warm up))
    opmode(OPMODE_STANDBY);
    // configure frequency
    configChannel();
    // set LNA gain
    //writeReg(RegLna, 0x20|0x03); // max gain, boost enable
    writeReg(RegLna, LNA_RX_GAIN);
    // configure receiver
    writeReg(FSKRegRxConfig, 0x1E); // AFC auto, AGC, trigger on preamble?!?
    // set receiver bandwidth
    writeReg(FSKRegRxBw, 0x0B); // 50kHz SSb
    // set AFC bandwidth
    writeReg(FSKRegAfcBw, 0x12); // 83.3kHz SSB
    // set preamble detection
    writeReg(FSKRegPreambleDetect, 0xAA); // enable, 2 bytes, 10 chip errors
    // set sync config
    writeReg(FSKRegSyncConfig, 0x12); // no auto restart, preamble 0xAA, enable, fill FIFO, 3 bytes sync
    // set packet config
    writeReg(FSKRegPacketConfig1, 0xD8); // var-length, whitening, crc, no auto-clear, no adr filter
    writeReg(FSKRegPacketConfig2, 0x40); // packet mode
    // set sync value
    writeReg(FSKRegSyncValue1, 0xC1);
    writeReg(FSKRegSyncValue2, 0x94);
    writeReg(FSKRegSyncValue3, 0xC1);
    // set preamble timeout
    writeReg(FSKRegRxTimeout2, 0xFF);//(LMIC.rxsyms+1)/2);
    // set bitrate
    writeReg(FSKRegBitrateMsb, 0x02); // 50kbps
    writeReg(FSKRegBitrateLsb, 0x80);
    // set frequency deviation
    writeReg(FSKRegFdevMsb, 0x01); // +/- 25kHz
    writeReg(FSKRegFdevLsb, 0x99);

    // configure DIO mapping DIO0=PayloadReady DIO1=NOP DIO2=TimeOut
    writeReg(RegDioMapping1, MAP_DIO0_FSK_READY|MAP_DIO1_FSK_NOP|MAP_DIO2_FSK_TIMEOUT);

    // enable antenna switch for RX
    hal_pin_rxtx(0);

    // now instruct the radio to receive
    hal_waitUntil(LMIC.rxtime); // busy wait until exact rx time
    opmode(OPMODE_RX); // no single rx mode available in FSK
}

static void startrx (u1_t rxmode) {
    ASSERT( (readReg(RegOpMode) & OPMODE_MASK) == OPMODE_SLEEP );
    if(getSf(LMIC.rps) == FSK) { // FSK modem
        rxfsk(rxmode);
    } else { // LoRa modem
        rxlora(rxmode);
    }
    // the radio will go back to STANDBY mode as soon as the RX is finished
    // or timed out, and the corresponding IRQ will inform us about completion.
}

// get random seed from wideband noise rssi
void radio_init () {
    hal_disableIRQs();

    // manually reset radio
#ifdef CFG_sx1276_radio
    hal_pin_rst(0); // drive RST pin low
#else
    hal_pin_rst(1); // drive RST pin high
#endif
    hal_waitUntil(os_getTime()+ms2osticks(1)); // wait >100us
    hal_pin_rst(2); // configure RST pin floating!
    hal_waitUntil(os_getTime()+ms2osticks(5)); // wait 5ms

    opmode(OPMODE_SLEEP);

    // some sanity checks, e.g., read version number
    u1_t v = readReg(RegVersion);
#ifdef CFG_sx1276_radio
    ASSERT(v == 0x12 );
#elif CFG_sx1272_radio
    ASSERT(v == 0x22);
#else
#error Missing CFG_sx1272_radio/CFG_sx1276_radio
#endif
    // seed 15-byte randomness via noise rssi
    rxlora(RXMODE_RSSI);
    while( (readReg(RegOpMode) & OPMODE_MASK) != OPMODE_RX ); // continuous rx
    for(int i=1; i<16; i++) {
        for(int j=0; j<8; j++) {
            u1_t b; // wait for two non-identical subsequent least-significant bits
            while( (b = readReg(LORARegRssiWideband) & 0x01) == (readReg(LORARegRssiWideband) & 0x01) );
            randbuf[i] = (randbuf[i] << 1) | b;
        }
    }
    randbuf[0] = 16; // set initial index

#ifdef CFG_sx1276mb1_board
    // chain calibration
    writeReg(RegPaConfig, 0);

    // Launch Rx chain calibration for LF band
    writeReg(FSKRegImageCal, (readReg(FSKRegImageCal) & RF_IMAGECAL_IMAGECAL_MASK)|RF_IMAGECAL_IMAGECAL_START);
    while((readReg(FSKRegImageCal)&RF_IMAGECAL_IMAGECAL_RUNNING) == RF_IMAGECAL_IMAGECAL_RUNNING){ ; }

    // Sets a Frequency in HF band
    u4_t frf = 868000000;
    writeReg(RegFrfMsb, (u1_t)(frf>>16));
    writeReg(RegFrfMid, (u1_t)(frf>> 8));
    writeReg(RegFrfLsb, (u1_t)(frf>> 0));

    // Launch Rx chain calibration for HF band
    writeReg(FSKRegImageCal, (readReg(FSKRegImageCal) & RF_IMAGECAL_IMAGECAL_MASK)|RF_IMAGECAL_IMAGECAL_START);
    while((readReg(FSKRegImageCal) & RF_IMAGECAL_IMAGECAL_RUNNING) == RF_IMAGECAL_IMAGECAL_RUNNING) { ; }
#endif /* CFG_sx1276mb1_board */

    opmode(OPMODE_SLEEP);

    hal_enableIRQs();
}

// return next random byte derived from seed buffer
// (buf[0] holds index of next byte to be returned)
u1_t radio_rand1 () {
    u1_t i = randbuf[0];
    ASSERT( i != 0 );
    if( i==16 ) {
        os_aes(AES_ENC, randbuf, 16); // encrypt seed with any key
        i = 0;
    }
    u1_t v = randbuf[i++];
    randbuf[0] = i;
    return v;
}

u1_t radio_rssi () {
    hal_disableIRQs();
    u1_t r = readReg(LORARegRssiValue);
    hal_enableIRQs();
    return r;
}

static CONST_TABLE(u2_t, LORA_RXDONE_FIXUP)[] = {
    [FSK]  =     us2osticks(0), // (   0 ticks)
    [SF7]  =     us2osticks(0), // (   0 ticks)
    [SF8]  =  us2osticks(1648), // (  54 ticks)
    [SF9]  =  us2osticks(3265), // ( 107 ticks)
    [SF10] =  us2osticks(7049), // ( 231 ticks)
    [SF11] = us2osticks(13641), // ( 447 ticks)
    [SF12] = us2osticks(31189), // (1022 ticks)
};

// called by hal ext IRQ handler
// (radio goes to stanby mode after tx/rx operations)
void radio_irq_handler (u1_t dio) {
    ostime_t now = os_getTime();
    if( (readReg(RegOpMode) & OPMODE_LORA) != 0) { // LORA modem
        u1_t flags = readReg(LORARegIrqFlags);
#if LMIC_DEBUG_LEVEL > 1
        lmic_printf("%lu: irq: dio: 0x%x flags: 0x%x\n", now, dio, flags);
#endif
        if( flags & IRQ_LORA_TXDONE_MASK ) {
            // save exact tx time
            LMIC.txend = now - us2osticks(43); // TXDONE FIXUP
        } else if( flags & IRQ_LORA_RXDONE_MASK ) {
            // save exact rx time
            if(getBw(LMIC.rps) == BW125) {
                now -= TABLE_GET_U2(LORA_RXDONE_FIXUP, getSf(LMIC.rps));
            }
            LMIC.rxtime = now;
            // read the PDU and inform the MAC that we received something
            LMIC.dataLen = (readReg(LORARegModemConfig1) & SX1272_MC1_IMPLICIT_HEADER_MODE_ON) ?
                readReg(LORARegPayloadLength) : readReg(LORARegRxNbBytes);
            // set FIFO read address pointer
            writeReg(LORARegFifoAddrPtr, readReg(LORARegFifoRxCurrentAddr));
            // now read the FIFO
            readBuf(RegFifo, LMIC.frame, LMIC.dataLen);
            // read rx quality parameters
            LMIC.snr  = readReg(LORARegPktSnrValue); // SNR [dB] * 4
            LMIC.rssi = readReg(LORARegPktRssiValue) - 125 + 64; // RSSI [dBm] (-196...+63)
        } else if( flags & IRQ_LORA_RXTOUT_MASK ) {
            // indicate timeout
            LMIC.dataLen = 0;
        }
        // mask all radio IRQs
        writeReg(LORARegIrqFlagsMask, 0xFF);
        // clear radio IRQ flags
        writeReg(LORARegIrqFlags, 0xFF);
    } else { // FSK modem
        u1_t flags1 = readReg(FSKRegIrqFlags1);
        u1_t flags2 = readReg(FSKRegIrqFlags2);
        if( flags2 & IRQ_FSK2_PACKETSENT_MASK ) {
            // save exact tx time
            LMIC.txend = now;
        } else if( flags2 & IRQ_FSK2_PAYLOADREADY_MASK ) {
            // save exact rx time
            LMIC.rxtime = now;
            // read the PDU and inform the MAC that we received something
            LMIC.dataLen = readReg(FSKRegPayloadLength);
            // now read the FIFO
            readBuf(RegFifo, LMIC.frame, LMIC.dataLen);
            // read rx quality parameters
            LMIC.snr  = 0; // determine snr
            LMIC.rssi = 0; // determine rssi
        } else if( flags1 & IRQ_FSK1_TIMEOUT_MASK ) {
            // indicate timeout
            LMIC.dataLen = 0;
        } else {
            ASSERT(0);
        }
    }
    // go from stanby to sleep
    opmode(OPMODE_SLEEP);
    // run os job (use preset func ptr)
    os_setCallback(&LMIC.osjob, LMIC.osjob.func);
}

void os_radio (u1_t mode) {
    hal_disableIRQs();
    switch (mode) {
      case RADIO_RST:
        // put radio to sleep
        opmode(OPMODE_SLEEP);
        break;

      case RADIO_TX:
        // transmit frame now
        starttx(); // buf=LMIC.frame, len=LMIC.dataLen
        break;

      case RADIO_RX:
        // receive frame now (exactly at rxtime)
        startrx(RXMODE_SINGLE); // buf=LMIC.frame, time=LMIC.rxtime, timeout=LMIC.rxsyms
        break;

      case RADIO_RXON:
        // start scanning for beacon now
        startrx(RXMODE_SCAN); // buf=LMIC.frame
        break;
    }
    hal_enableIRQs();
}

The entire file, really?

And text posted as text isn’t an option, it’s helping with the forum search, which you could try …

As well as reviewing the README relating to radio cfg as implied by the lines around 689 …

You could just paste the few lines concerned in stead of the entire file…

Can you use search? This isn’t the first time a question has been asked about this error. The last time was less than a week ago… also googling what an assert is used for might enlighten you what is wrong.
Hint, controller seems not get the right result from the rfm module. Are you pin mappings correct??

Sorry I thought you asked for the whole file.
I’m a debutant here.It’s my firts time on forums.

Yes I saw that some were talking about pin mapping problem. But how to check the pin mapping?
Sorry if my questions seem obvious to you, I just don’t understand.
And thank you in advance for your understanding.

Try looking around more to see how things are done - but even so, things like search are pretty universal to the operation of the web and you don’t appear to have tried that despite two people suggesting it.

As per my suggestion and my big hint above, read the README.

By encouraging you to use the resources to help yourself, you will make much faster progress in the coming weeks.

Check the documentation on what is required, check the circuit diagram of your hardware on what connects to what and take a close look at the header top right in your picture as you might need to add jumpers there!

Okay thank you so much
Your support has been very helpful to me.

Ok I’ll do that rightnow and I’ll get back to you soon

Can you help me please.
I don’t see the README.

Here is the Pin used by RFM95 on the Arduino
Pins usage on Arduino
D2 - RFM95_INT
D9 - RFM9x_RS
D10 - RFM9x_CS
D11 - RFM9x MOSI
D12 - RFM9x MISO
D13 - RFM9x SCK

So my mapping is it correct?

const lmic_pinmap lmic_pins = {
    .nss = 10,
    .rxtx = LMIC_UNUSED_PIN,
    .rst = 9,
    .dio = {2, 6, 7},
};

Have you checked the circuit diagram and the jumpers you might need to add?

How did you get hold of LMIC? From where, how installed? Can you look online for it? Or search on your computer?

What do you mean by connecting with jumpers?

I installed LMIC via the bookstore library. I installed MCCI LORAWAN LMIC

Here is the equipment’s link : LoRa Radio Shield (868MHz) | Makerfabs

I noted the absence of jumper but my main problem remains the pin mapping and I still don’t know if my pin mapping is good

If you do not fit jumpers there is no connection between the rfm95 and the Arduino for Dio1, Dio2 and Dio5. Does LMIC need any of these signals???
